Tags: Android, STB, IPTV, OTT

PLUM SMART BOX - Android OS-DV8220-S905X NEW

  • 20$
  • DV8220 is a  quad-core 4K android OTT set-top box.It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoDSpecificationDV8220 Amlogic S905XM..
    • Ex Tax:20$
    • Brands Amlogic
    • Product Code: PLUMiTVSMARTBOX-AndroidOS-DV8220-S905XNEW
    • Availability: In Stock

    DV8220 is a  quad-core 4K android OTT set-top box.It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoD


    Specification
    DV8220 Amlogic S905X
    Main features

    64-bit CPU

    4Kp60 HEVC Main-10 Decoding

    VP9 up to 4K*2K@60fps

    Support HDR

    HDMI 2.0b, CEC, HDCP2.2

    Streaming Protocol: RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming

    DRM: Widevine, Playready, Verimatrix

    Management Features: TR069

    Multi-screen interaction: Miracast, DLNA, Airplay

    Air Remote: Can use the Android and iOS mobile phone to control

    System

    CPU: ARM Quad 64-bit Cortex-A53 up to 1.5GHz DVFS

    GPU: Penta Core Mali-450 up to 750MHz + DFS

    DRAM: DDR3 1GB (2G Optional)

    Flash: eMMC 8GB (4GB, 16GB, 32GB, 64GB Optional)

    OS: ANDROID AOSP

    Connectivity

    Video output - HDMI2.0b, AV

    Network:  RJ45 Interface 10M/100M adaptive

    Build in Wi-Fi 2.4GHz 802.11b/g/n

    Peripheral interface - USB 2.0 x2, Micro SD card

    Power interface - DC 5V

    Other interface

     Front panel: Standby key, IR receiver, Power/IR/Net LED indicator

    Media

    Video Decoder:

    H.265 10-bit 4K*2K@60fps, H.264 AVC/MVC 4K*2K@30fps, VP9, AVS+,MPEG1/2/4 ASP,WMV/VC-1, RealVideo8/9/10

    Format: MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV,3GP, DIVX, F4V, ASF, M2V etc

    Audio Decoder:

    MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional)

    Format: MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.

    Subtitle format: SRT, ASS, SSA etc.

    Input voltage

    DC in 5V/2A
